It may be confusing on how to use this variable potentiometer.
However the schematics below can help you out.
The schematics has 5 pins.
The power pin is seen which links to the second pin via the switch lever once turned on.
The second pin should connect to the middle pin amid other 3 pins. On the left of the middle pin is the pin that should connect to device to be controlled e.g., LED light.
